• Auto discriminate barcodes
• Laser 200 scan/sec
• Flexible custom configuration
• Light weight for minimum fatigue
• Low power consumption
• Powerful build-in decoder
• PS/2 interface
| Width Of Window | 5.5CM |
| Light source | Visible Laser Diode 650 nm ± 10 nm |
| Scan Depth of Field | 10~400 mm |
| Resolution | ≥3mil |
| Print Contrast Ratio | 30% minimum reflective difference |
| Scan Rate | 200 Scans/Lines/Sec |
| Symbologies | UPC/EAN, UPC/EAN with Supplementals, UCC/EAN 128, Code 39, Code 39 Full ASCII, Trioptic Code 39, Code 128, Code 128 Full ASCII, Coda bar, Interleaved 2 of 5, Discrete 2 of 5, Code 93, MSI, Code 11, RSS variants, Chinese 2 of 5，MSI/Plessey，UK/Plessey，UCC/EAN 128，Chinese code ，GS1 Data Bar（RSS）series |
| Scanning Angle | Left-right: ±60° Forward-back: ±65° Spin: 42° |
| Operating Temperature | 0°C -45°C |
| Storage Temperature | -40°C -60°C |
| Humidity | 5%-90% (non-condensing) |
| Light Level | 5,000 LUX |
| Shock / Drop | 1.5 m with packaging |
| Voltage | DC 5V ±0.25V |
| Power Consumption | 100 mA |
| Housing | ABS |
| Interface | RS232/ USB |
| Cable | ≤2m |
| Dimension | 191 L × 69.5 W × 70.9 H (mm) |
| Weight | 445g (with stand) |
| Color | Black |
| Safety | FCC Class B/ CE |
| Laser Class | Class 2 |
| IP rating | N/A |
