| Key Features |
•With 78 Cherry MX keys based on Gold Crosspoint technology |
| and have tactile feeling |
| •Two different key actions (soft contact and keyclick) |
| •Laser-engraved keycap symbols or high quality UV silk screen |
| printed keycap symbols |
| •Operating life cycle of individual keys: |
| - Soft contact mode: 50 million strokes |
| - Key click mode: 20 million strokes |
| •Damaged keys can be easily replaced and hence save the |
| replacement cost |
| •With internal metal plate for key fixation, the protection against |
| ESD is increased |
| •Different relegendable keycaps (1-fold, 2 fold, 4 fold) are available |
| MagStripe Reader Features |
•Comply with ISO 7812, IBM standards, American Driving License |
| •Support programmable MSR setting for the header, tailor, |
| separator, suffix and prefix, track sequence |
| •Support multi-country code settings |
| •Track 1: 210BPI with max 76 characters |
| •Track 2: 210BPI with max 107 characters or 75BPI with |
| max 37 characters |
| •Track 3: 210BPI with max 107 characters |
| •Card swipe speed: 10 to 100 cm/s |
| •500,000 swipe cycles |
| •Available Configuration |
| - Dual Track: Track 1 & 2 or Track 2 & 3 |
| - Three Track: Track 1, 2 & 3 |
| Programmable Features |
•All keys can be programmed with unlimited characters |
| •All data can be retained for no less than 100 years without |
| additional battery |
| •Does not require a TSR program and hence avoids application |
| software crashes |
| •Provides multi-level programming |
| •Provides for a variable time delay of up to 255 seconds in each |
| programmed string |
| •Provides true keyboard wedge function that operates with or |
| without the normal computer keyboard connected |
| •Provide a true Caps/Scroll/Numeric Lock function independent |
| of any other keyboards being connected |
| •Support PS/2 programming in DOS, Windows9X, Me, 2K, XP |
| Keylock Features |
•6 steps keylock |
| •Life cycle >= 25,000 times |
| •Have tactile feeling |
| Power Supply |
PS/2: +5V/DC +-10%; <100mA |
| USB: +5V/DC +-5%; <100mA |
| Storage Temperature |
-40C to +60C |
| Operating Temperature |
0C to +50C |
| Operating humidity |
20% to 90% |
| Dimension |
290L x 175W x 52H (mm) |
| Weight (g): |
|
| Total travel |
4 - 0.4mm |
| Pre-travel |
2 +- 0.6mm |
| Peak load before make |
60 +- 20cN |
)
