Application

• Hands-Free, Presentation Scanning

DIMENSIONS

Weight

• 340 g
• 12 oz

Overall Dimensions

• 3.2\ x 1.6\ x 4.1\ no stand; 3.2\ x 1.6\ x 5.7\ with stand
• 80 mm x 40 mm x 105 mm no stand; 80 mm x 40 mm x 145 mm with stand

SCANNING SPECIFICATIONS

Pitch

• 65°

Skew

• 65°

Scanning Range

• Standard range SR

Scan Pattern

• Area Image, 1,280 x 800 pixel

Maximum Brightness

• 100,000 Lux

Decode Capability

• 1D/2D

Print Contrast

• 20% minimum reflectance difference

Motion Tolerance

• 400 cm/s for 13 mil UPC at optimal focus

HARDWARE

Engine Type

• 1D/2D

Host System Interface

• USB, RS-232, Keyboard Wedge, IBM 46xx RS-485

ELECTRICAL

Operating Current

• 2.0 W 400 mA @ 5V

Input Voltage

• 5.0V DC Typical

ENVIRONMENTAL

Operating Humidity

• 0% to 95% relative humidity, non-condensing

Storage Temperature Range

• -40°C to 70°C
• -40° F - 158° F

Operating Temperature

• 32° F - 122° F
• 0°C to 50°C

SERVICE TERMS

Warranty Duration

• 3 Years

OTHERS

Power Connector Type

• Corded
