• Support 1D
• Short/Long Distance Dual Lenses
• Automatic Detect Reading Mode
• Colored Aiming Blue Light
• Dropping From 1.2m
| Width Of Window | 3cm Max |
| Light source | 630nm |
| Scan Depth of Field | 50~300mm |
| Resolution | 4mil |
| Print Contrast Ratio | MAX. 20% |
| Scan Rate | 200 Scans/Sec |
| Symbologies | UPC-A/ UPC-E/ CODE11/ CODE 39/ CODE 93/ CODE128/ EAN-8/ EAN-13/ Codabar/ GS1-128/ GS1 Limited/ GS1 Omnidirectional/ ISBN/ ISSN/ ISBT/ Interleaved 2 of 5/ Matrix 2 of 5/ Industrial 2 of 5/ MSI/ Plessey/ ITF14/ China Post |
| Baud Rate | 9600 |
| Connection Range | 5-20cm |
| Operating Temperature | -20°～50° |
| Storage Temperature | -20°～70° |
| Humidity | 5 - 95% RH |
| Shock / Drop | 1.5 m with packaging |
| Voltage | 5V DC |
| Power Consumption | 80 mA |
| Charge Mode (Wireless only) | N/A |
| Charge time (Wireless only) | N/A |
| Battery Capacity (Wireless only) | N/A |
| Material | ABS |
| MCU | ARM 32bit |
| Memory | N/A |
| Interface | USB/RS232 |
| Cable | 1.8m |
| Dimension | 170 L × 66 W × 85 H (mm) |
| Weight | 115g |
| Color | black |
| Safety | FCC Class B/ CE |
| IP Rating | IP54 |
