| Key Features |
•With 104 Cherry MX keys based on Gold Crosspoint |
| technology and have tactile feeling |
| •Two different key actions (soft contact and keyclick) |
| •Laser-engraved keycap symbols or high quality UV |
| silk screen printed keycap symbols |
| •Operating life cycle of individual keys: |
| - Soft contact mode: 50 million strokes |
| - Key click mode: 20 million strokes |
| •Damaged keys can be easily replaced and hence save the replacement cost |
| •With internal metal plate for key fixation, the protection against |
| ESD is increased |
| •Can be upgraded to programmable version |
| MagStripe Reader Features |
•Comply with ISO 7812, IBM standards, American Driving License |
| •Support programmable MSR setting for the header, |
| tailor, separator,suffix and prefix, track sequence |
| •Track 1: 210BPI with max 76 characters |
| •Track 2: 210BPI with max 107 characters or 75BPI with max 37 characters |
| •Track 3: 210BPI with max 107 characters |
| •Card swipe speed: 10 to 100 cm/s |
| •500,000 swipe cycles |
| •Available Configuration |
| - Dual Track: Track 1 & 2 or Track 2 & 3 |
| - Three Track: Track 1, 2 & 3 |
| •Support multi-country code settings |
| •USB, PS/2 interfaces are avaliable |
| Power Supply |
PS/2: +5V/DC +-10%; <100mA |
| USB: +5V/DC +-5%; <100mA |
| Storage Temperature |
-40C to +60C |
| Operating Temperature |
0C to +50C |
| Operating humidity |
20% to 90% |
| Dimension |
470L x 190W x 45H (mm) |
| Weight (g): |
1430 |
| Total travel |
4 - 0.4mm |
| Pre-travel |
2 +- 0.6mm |
| Peak load before make |
60 +- 20cN |
)
