•Command protocal is based on ECS / POS Standard
•Low-noise thermal printing
•Repeated operation and compy printing are possible
•Character font size (12*24 font & 24*24 font) optional
•Built-in interface provides control capabilit for cash drawer
| Print Method | Direct thermal line |
| Print Resolution | 203dpi |
| Max Printing Speed | 90mm/s |
| Max Printing Width | 48mm |
| Kitchen Print | NO |
| OS Support | Windows OS |
| Width | 58±0.5mm |
| Thickness | 0.054~0.06 mm |
| Character Set | ANK Font Font A: 12×24dots Simplified/Traditional : 24×24dots |
| Character/Line | 3.75mm(can be adjusted by sending commands) Font A - 42columns or 48columns Font B:56columns or 64columns/ Simplified/Traditional Chinese - 21columns or 24columns |
| Barcodes Supported | UPC-A/UPC-E/JAN13(EAN13)/JAN8(EAN8)CODE39/ITF/CODABAR/CODE93/CODE128 |
| Mechanism (km) | 50km |
| Auto Cutter | NO |
| Dimensions(WxDxH) | 140 W × 222 D × 210 H (mm) |
| Packing dimension | 295 W × 210 D × 183 H (mm) |
| Net Weight | 0.92KG |
| Gross Weight | 1.7KG |
| Power Input | AC 110V/220V,50-60Hz |
| Power Output | DC 12V/3A |
| I/O Ports | Serial/ USB/ Parallel/ Ethernet |
| Operating Temperature | 0 to 45℃ |
| Humidity | 10 - 80% RH |
| Safety | FCC/ CE/ RoHS |
