3 Track Programmable Magnetic Card Reader & Writer
EC-MSR900
返回
  • Compatible with instructions:100% compatible with MSR206 instruction set.

  • Easy & convenience: The built-in battery without external power supply, do not need to install the driver.

  • Read-write functions: For high/low magnetic stripe (300-4000 OE) all three rail to read and write function.

  • Read- write format: Support ISO, AAMVA DMV custom and so on the many kinds of magnetic recording format, speaking, reading and writing.

  • Blind read function: Reading card/deposit book which can realize the different standard of the blind to read.

Electrical



Power supply

5V

Build-in Battery Capacity

600mAh

Consumption

Read

50mA±15%

Write

2800mA±15%

Communication

USB

Mechanical



Model

MSR900S

Body material

ABS 94V

Size

150mm(L)X50mm(W)X53mm(H)

Weight

950g

Color

Black

Environment



Operation temperature

-10℃ ~ 55 ℃

Operating humidity

10%~85%  relative humidity

Storage temperature

-30℃~70℃

Store humidity

10%~90% relative humidity

Performance



Track

1/2/3 tracks

Recording density

1、3 track

210BPI

2 track

75/210BPI optional

Coercive force

Read/Write 300-4000 oe Mag card

Operating speed



Read speed

6.3~250cm/s

Write speed

10~100cm/s

Card thickness

PVC 0.76±0.08mm

Error rate

Read < 0.5%、Writer < 0.8%

Head life

About 1,000,000 times

Safety approval



Rating

CE, FCC,ROHS
