熱感收據打印機
EC-PM-X30
返回

• 58mm/80mm/82.5mm paper width available

• IAP function supports firmware update within 5S

• Emulation Driver ESC/ POS Windows/ J POS/Linux/ Android/ Mac

• Metallic frame mechanism

• Flexible interface options

Printing method

Direct thermal



Printing speed

300mm/s







Interface

USB + Ethernet

Paper width

79.5±0.5mm



Print width

57.5/72/80 士0 . 5mm



Paper thickness

0.06~0.08mm



Column capacity

576 dots/line(adjustable by command)



Line space

3.75mm(Changeable by commands)



Column number

80mm paper: Font A - 42 columns or 48 columns/Font B - 56 columns or 64 columns/

Chinese, traditional Chinese - 21 columns or 24 columns



Character size

ANK, Font A: 1.5 x 3.0m m(12x2 4 dots) Font B: 1.1x2.1mm(9x17 dots)

Chinese, traditional Chinese :3.0 x 3.0mm(2 4 x2 4 dots)



Dimension

133x126x130mm (DxWxH)



Gross weight

1.115 kg



Bar code

UPC-A/UPC-E/ JAN13(EAN13)/ JAN8(EAN8)/CODE39/ITF/CODABAR/CODE93/CODE128



QR CODE、PDF417



Code page

PC34 7(Standard Europe)/ Katakana/ PC850(Multilingual) / PC860(Portuguese) / PC863(Canadian-French) / PC865(Nordic) / West Europe/ Greek/ Hebrew/

East Europe/ lran/WPC1252 / PC866(Cyrillic#2) / PC852(Latin2) / Pc858 / lranll /Latvian/ Arabic/ PT151(1251)




Auto Cutter

Partial



Cutter life

2 million cuts



Print head life

150KM



Input buffer

2048 Kbytes



NV Flash

256 Kbytes



Power adaptor

AC220V, 50~60Hz



Power source

DC 24V/2.5A



Cash drawer output

DC 24V/1A



Work environment

Temperature: 0~45°C , humidity: 10~80RH%



Storage environment

Temperature: -10~60°C, humidity: 10~90RH%



Emulation

ESC/POS



Driver

Windows/ JPOS/Linux/ Andra id/Mac



Utility

Windows & Linux test Utility



SDK

iOS, Android, Windows


驅動程式
Drivers
Utility
用戶手冊
EC-X30 User manual
下載
規格單張
EC-PM-X30 SERIES
下載
