銷售點終端機
EC-1519
返回

• Bezel free design

• Low speed mute fan heat treatment system

• Detachable hard disk installation

• Convenient unification of the operating system installation

• Optimize arrangement of connecting wire

• The obverse side waterproof and dustproof IP65

• Selectable and upgrade able Ports

CPU 4th Generation Intel®  Core™ i3 Processors /Mobile
Memory DDRIII-1600 4GB (up to 8GB)
Storage 320GB HDD or up /
64G SSD (up to 256GB)
OS Support Windows 7, Windows 8.1, Windows Embedded 8.1 Industry,
 Windows 10, Windows 10 IOT, POS Ready 7, Linux (ubuntu)
Display Size 15"
Resolution XGA 1024*768
Brightness 350cd /㎡
Backlight Type WLED
Contrast Ratio 700:1
Response Time  2(Tr)/10(Td)ms
Viewing Angle (Up/ Down/ Left/ Right) 70/70/80/80
Video Interface LVDS
Touch 15" Bezel Free Resistive
I/O Port DC IN(DC 2.5)
POWER ON/OFF
1×HDMI
1×VGA
2×USB2.0
2×USB3.0
1×LAN
1×MIC
1×LINE
2*COM(DB9)


Housing Material Magaluma
Tilt Angle 60°
VESA Mounting  100*100MM
Dimensions (W x D x H) 369*195*353MM
Packing Dimension 460*250*410MM
Net Weight 6.1kg
Gross weight 8.0kg
Consumption 50W(MAX)
Operating Temperature  0 ℃ to 40℃
Storage Temperature  -20℃ to 60℃
Humidity 20﹪~80﹪(RH)
Shock / Drop Class A Package  1~20.99 lbs(0.45~9.54㎏) 30 in /(76.20㎝)
Power Input AC 100-240V/50-60HZ  1.5A
Power Output DC 12V/5A
Safety FCC / CE / RoHS
IP Rating IP54
ISO Trick 1/2/3 Magnetic Stripe Reader  support
VFD support
Second Display (9.7", 10.1", 12", 15") 9.7"
Wireless support
iButton support
iButton+MSR N/A
Finger Senor N/A
