• Ideal for customers with low volume of POS transactions

• Featuring Epson quality and reliability

• Printing speeds of up to 200mm/second for text and graphics

• Flexible coupon printing on receipts

Print method Thermal line printing
Print fonts(True type) Font A 12(W) x 24(H) mm
  Font B 9(W) x (H) mm
Column Capacity Standard: Paper width 80mm: 48/84; Paper width 58mm: 35/46
  42 Column Mode: Paper width 80mn: 42/60; Paper width 58mn: 42/31
Character size(mm) Font A: 1.25(W) x 3(H), Font B : 0.88(W) x 2.13(H)
Character set  95 Alphanumeric, 18sets International, 128 x 43 Extend Graphics
Bar code: UPC-A, UPC-E, JAN13(EAN13), JAN8(EAN), CODE39, ITF,
CODABAR(NW-7), CODE93, CODE128, GS1-128,
GS1 DataBar Two-dimensional code, PDF417, Qrcode, MaxiCode,
Two-dimensional GS1 DataBar, Composite Symbology
Character per inch Font A: 16.9 cpi, Font B: 22.6 cpi
Interfaces USB + Serial, USB + Parallel, Ethernet
Receive data buffer 4 KB or 45 bytes
Print speed Max. 200mm/sec
Resolution 203 dpi x 203 dpi
Paper dimensions(mm) 79.50 ± 0.50 (W) mm x dia 83.00 mm
57.50 ± 0.50 (W) mm x dia 83.00 mm
Power 24 VDC ± 7%
Power consumption Operating: Approx. 1.8A(Mean / Print ratio 18% with print pattern)
Standby: Approx. 0.1A (Mean)
Power supply External power supply( Model: PS-180)
Printer mechanism life 15 million lines( printing + Paper feeding)
Auto cutter life 1.5 million cuts
MTBF 360,000 hours
MCBF 60,000,000 lines
EMI and safety standard Oceania EMI AS/NZS CSPR22 Class A
Standard accessories Roll paper x 1 roll (for checking the initial movement of the printer),
CD-ROM (Drivers, Utility software, Manuals), Setup guide, Power button
cover, Waterproof power button cover, Wall hanging bracket, Screws for
wall hanging bracket, Rubber feet for vertical installation, Control panel
sheet for vertical installation, 58-mm width paper guide, External power
supply ( Model: PS-180), AC cable (May not be included depending on
the printer model)
Overall dimensions 140mm (W) x 199mm (D) x 146mm (H)
Weight 1.7kg
