觸控顯示器
EC-TS-1710
返回

• True Bezel Free Designing

• High Performance 17 inch LED Panel

• 5-wire resistive touch

• Ergonomics stylish “L” shape stand

• Drip-proof sealed screen

• Optional for different stands; ISO Track 1/2/3 Magnetic Strip

   Reader; VFD

Display Size 17 inches
Resolution 1280 × 1024
Brightness 400cd /㎡
Backlight Type WLED
Contrast Ratio 1000:1
Response Time  12ms
Viewing Angle (Up/ Down/ Left/ Right) 80°/80°/85°/85°
Video Interface LVDS
Touch 5-wire Resistive / Projected Capacitive
I/O Port DC 12V IN(DC 2.0)
1×VGA
1×Touch USB (Type B)

Housing Material ABS+Magaluma
Tilt Angle 0°~60°
VESA Mounting  100×100 mm
Dimensions (W x D x H) AT Stand:
395 W × 175 D × 364 H (mm)
L Stand:
395 W × 195 D × 364 H (mm)
Packing Dimension 490 W × 210 D × 450 H (mm)
Net Weight AT Stand: 5.5KG  /
L Stand: 6.0KG
Gross weight AT Stand: 7.2KG  /
L Stand: 7.7KG
Consumption 25W (MAX)
Operating Temperature  0 ℃ to 40℃
Storage Temperature  -20℃ to 60℃
Humidity 20 - 80%  RH
Shock / Drop 76.2cm with packaging
Power Input AC 100-240V/1.5A
Power Output DC 12V/3A
Safety FCC, CE, ROHS
IP Rating IP 54
