EC-FDS(I)

Model

EC-FDS(I)

Screen Size

32" 43" 49" 55" 65"

Resolution (pixels)

Full HD 1920 x 1080 or UHD 3840 x 2160

Brightness

500cd/m² ( Optional up to 700cd/m² )

LCD Type

LG - IPS

Response Time

8ms

Contrast Ratio

1400:1

Color System

PAL / NTSC / Auto

Touch

10-point Projected Capacitive Touch (Optional)

Viewing Angle

80°/80°/70°/70° ( Up/ Down/ Left/ Right )

Display Area

Dimension with Standard Wheels & Weight

32" : 394H x 700V mm

32" : 446W x 1739H x 53D mm | Bass : 446W x 400D mm | Weight : 22KG

43" : 532H x 943V mm

43" : 583W x 1855H x 53D mm | Bass : 598W x 400D mm | Weight : 36.3KG

49" : 606H x 1075V mm

49" : 658W x 1925H x 53D mm | Bass : 672W x 450D mm | Weight : 42.4KG

55" : 680H x 1209V mm

55" : 734W x 1975H x 53D mm | Bass : 749W x 480D mm | Weight : 48.5KG

65" : 806H x 1430.5V mm

65" : 857W x 2125H x 53D mm | Bass : 872W x 500D mm | Weight : 61KG

O/S

Android or Windows

Operating System

Android 7.0 / 9.0 / 11 / 12 / 13 or Windows J6412 / i3-12th / i5-12th or Other

Wireless

Onboard，802.11b/g/n

LAN Connectors

Yes

HDMI Connectors

Yes

USB Connectors

Yes

Mic-in/Line-out

Yes

AC Power Switch

Yes

Audio

Built-in 8Ω5W Speaker x 2

Power Requirement

AC100V～240V，50/60Hz

Mechanical

Aluminum + Metal Back Cover + Tempered Glass Panel

Operating Temperature

0℃ to 50℃

Storage Temperature

-20℃ to 60℃

Included

Power Cord / Remote Control
