Dimensions (L x W x H)
99 mm x 64 mm x 165 mm (3.9 in x 2.5 in x 6.5 in)

Scanner Weight
160 g (5.6 oz)

Input Voltage
4.4V DC – 5.5V DC

Operating Power (Charging) Bases
2.5W (500 mA @ 5V DC)

Host System Interfaces
USB, Keyboard Wedge, RS-232, RS485 support for TGCS (IBM) 46XX

User Indicators
Good Decode LEDs, Rear View LEDs, Beeper (adjustable tone and volume), Vibration (optional)

Operating Temperature
0°C to 50°C (32°F to 122°F)

Storage Temperature
-40°C to 70°C (-40°F to 158°F)

Electrostatic Discharge (ESD) (Scanners and Cradles)
±8 kV indirect coupling plane, ±15 kV direct air

Humidity
0% to 95% relative humidity, non-condensing

Tumble
2,000 0.5 m (1.6 ft) tumbles (impacts)

Drop
Engineered to withstand 50 1.8 m (6 ft) drops to concrete

Environmental Sealing
IP41

Light Levels
0 to 100,000 lux (9,290 foot-candles)

Scan Pattern
Area Image (1280 x 800 pixel array)

Motion Tolerance
Up to 400 cm/s (157 in/s) for 13 mil UPC at optimal focus

Scan Angle
SR: Horizontal: 48°; Vertical: 30°
HD: Horizontal: 48°; Vertical: 30°

Print Contrast
20% minimum reflectance difference

Roll, Pitch, Skew
±360°, ±45°, ±65°

Decode Capabilities
Reads standard 1D, PDF, 2D, Postal Digimarc, DOT Code, and OCR symbologies
Note: Decode capabilities dependent on configuration
