Barcode Scanner

Honeywell HH490

HH490 is designed for commercial environments requiring high speed 1D/2D scanning operations. The imager is able to read bar codes rapidly and continuously, even when reading damaged, partially obscured, or poorly printed bar codes.

HH490系列專為要求快速進行一維/二維掃描操作的商業環境而設計,擁有工業級產品的可靠性和卓越的條碼識別能力,即使面對破損和污損的條碼,仍可輕鬆應付。

Dimensions (L x W x H)

72.5mm×125mm×154mm (2.85 in 4.92 in 6.06 in)

Scanner Weight

130 g (4.58 oz)

Input Voltage

5 ± 0.5VDC

Operating Power

2 W (400 mA @ 5V DC), Standby Power: 0.55 W (110 mA @ 5V DC), Host System Interfaces: USB, RS-232

Operating Temperature

0°C to 50°C (32°F to 122°F)

Storage Temperature

-40°C to 60°C (-40°F to 140°F)

Electrostatic Discharge (ESD) (Scanners and Cradles)

±8 kV indirect coupling plane, ±15 kV direct air

Humidity

0% to 95% relative humidity, non-condensing

Tumble Spec

250 0.5 m (1.6 ft) tumbles (impacts) Drop: Engineered to withstand 1.2m 2times drop to concrete

Environmental Sealing

IP40

Light Levels

0 to 100,000 lux (9,290 foot-candles

Scan Pattern

Area Image (1280 x 800, pixel array)

Motion Tolerance

up to 75 cm/s for 13 mil UPC at optimal focus

Scan Angle

Horizontal: 48° nominal

Vertical

30° nominal

Roll, Pitch, Skew

±180°, ±60°, ±65°

Minimum Contrast

25%

Decode Capabilities

Reads standard 1D, PDF, 2D, and DotCode symbology

Note

Decode capabilities dependent on configuration
